尺寸图
规格书
单位/ mm
| 型式/ 规格 | A | B | C (h7) | D | E | F | E1 | F1 | G (HB) | H |
| LS1120RE | 110 | 20 | 145 | 128 | 42 | 30 | 42.5 | 31 | 22 | M20x2.5P |
| LS1221RE | 120 | 21 | 168 | 145 | 44 | 32 | 42.5 | 31 | 22 | M20x2.5P |
| LS1330RE | 130 | 30 | 168 | 150 | 51 | 36 | 52.5 | 32.5 | 26 | M24x3P |
| LS1120REA | 110 | 20 | 145 | 128 | 42 | 30 | 42.5 | 31 | 22 | M20x2.5P |
| LS1221REA | 120 | 21 | 168 | 145 | 44 | 32 | 42.5 | 31 | 22 | M20x2.5P |
| LS1330REA | 130 | 30 | 168 | 150 | 51 | 36 | 52.5 | 32.5 | 26 | M24x3P |
| 型式/ 规格 | J | K | A1 | B1 | C1 | D1 | L | M max. | M min |
| LS1120RE | 35 | 135 | 7 | 19 | 54.5 | 24.5 | 74.5 | 49.9 | 29.9 |
| LS1221RE | 35 | 138 | 9 | 21 | 53 | 23 | 74.5 | 49.9 | 28.9 |
| LS1330RE | 35 | 155 | 10 | 22 | 63 | 32.5 | 84.5 | 60 | 30 |
| LS1120REA | 35 | 135 | 9.9 | 21.9 | 52.9 | 22.9 | 74.5 | 49.9 | 29.9 |
| LS1221REA | 35 | 138 | 8.9 | 20.9 | 52.9 | 22.9 | 74.5 | 49.9 | 28.9 |
| LS1330REA | 35 | 155 | 10 | 22 | 63 | 33 | 84.5 | 60 | 30 |
| 型式/ 规格 | N | P max. | P min | Q | R | T | 活塞行程 (mm) | 最高回转速 rpm(min -1 ) |
| LS1120RE | 163 | 60 | 40 | 6-M8x1.25P | 125 | 17 | 20 | 6000 |
| LS1221RE | 186 | 60 | 39 | 6-M10x1.5P | 128 | 16 | 21 | 6000 |
| LS1330RE | 186 | 60 | 30 | 6-M10x1.5P | 145 | 19 | 30 | 6000 |
| LS1120REA | 163 | 60 | 40 | 6-M8x1.25P | 125 | 17 | 20 | 6000 |
| LS1221REA | 186 | 60 | 39 | 6-M10x1.5P | 128 | 16 | 21 | 6000 |
| LS1330REA | 186 | 60 | 30 | 6-M10x1.5P | 145 | 19 | 30 | 6000 |
| 型式/ 规格 | 惯性矩 (kg-m 2 ) | 流量 (l/min) | 最大设定压力 kgf/cm 2 (Mpa) | 活塞面积( cm 2 ) | 最大推(拉)力 | 净重 (kg) | 注气压力 | ||
| 推力侧 kgf (KN) | 拉力 kgf (KN) | 推力 kgf (KN) | 拉力 kgf(KN) | Max. Press kgf/cm 2 (Mpa) | |||||
| LS1120RE | 0.02 | 1.2 | 35 (3.4) | 89.6 | 84.8 | 2800 (27.5) | 2700 (26.5) | 8.2 | - |
| LS1221RE | 0.03 | 1.2 | 40 (3.9) | 107.7 | 102 | 3900 (38) | 3800 (37) | 10.8 | - |
| LS1330RE | 0.03 | 1.2 | 40 (3.9) | 127.4 | 119.4 | 4600 (45) | 4300 (42) | 11.4 | - |
| LS1120REA | 0.02 | 1.2 | 35 (3.4) | 88.6 | 84.8 | 2800 (27.5) | 2700 (26.5) | 8.25 | 10.2 (1.0) |
| LS1221REA | 0.03 | 1.2 | 40 (3.9) | 106.7 | 102 | 3900 (38) | 3800 (37) | 10.8 | 10.2 (1.0) |
| LS1330REA | 0.03 | 1.2 | 40 (3.9) | 126.4 | 119.4 | 4600 (45) | 4300 (42) | 11.4 | 10.2 (1.0) |
流量测试标准-压力: 30kgf/cm 2 (2.94Mpa) 油温50°C
| Model | 2D pdf | 2D dwg | 3D step |
|---|---|---|---|
| 尺寸 |
|
|
|
| 规格 |
|
|
|
