Spec
                 Model

Order NO.

Spindle nose NO.

Thru-hole(Diameter) mm

Jaw stroke(Diameter) mm

Plunger stroke mm

Gripping Max

Gripping Min

Max. permissible input force KN(kgf)

CAH-05

1AH05

-

33

5.4

10

135

10

17.5(1784)

CAH-06

1AH06

A2-5

46

5.5

13

169

13

25(2500)

CAH-08

1AH08

A2-6

52

7.6

18

210

11

40(4080)

CAH-10

1AH10

A2-8

77

8.5

20

25.4

31

50(5100)

CAH-12

1AH12

A2-8

91

10.2

24

304

34

58(5916)

CAH-15

1AH15

A2-11

118

10.6

23

381

30

71(7240)

CAH-18

1AH18

A2-11

118

10.6

23

450

30

71(7240)

CAH-21

1AH21

A2-11,      15

140

10.6

23

530

87

90(9177)

CAH-24

1AH24

A2-11,      15

165

10.4

23

610

110

90(9177)

CAH-32

1AH32

A2-15,20

240

18

34

800

152

100(10193)

Spec
                 Model

Max. static gripping force KN(kgf)

Max. Permissible speed r.p.m

weight(With standard soft jaws)

Gd moment of inertia

matching cylinder

Matching hard jaw

Matching soft jaw

CAH-05

36(3671)

7000

6.7

0.7(0.071)

YAH-05

HJ-04A1

SJ-05T1

CAH-06

63(6426)

6000

12.5

2.26(0.23)

YAH-06

HJ-06T1

SJ-06T1

CAH-08

94(9597)

5000

22.3

66.7(0.68)

YAH-08

HJ-08T1

SJ-08T1

CAH-10

125(12740)

4200

34.5

12.84(1.31)

YAH-10

HJ-10T1

SJ-10T1

CAH-12

147(15000)

3300

55.3

28.71(2.93)

YAH-12

HJ-12A1

SJ-12A1

CAH-15

180(18355)

2500

120

89.14(9.09)

YAH-15

HJ-15T1

SJ-15A1

CAH-18

180(18355)

2000

164

174.6(17.8)

YAH-15

HJ-15T1

SJ-15A1

CAH-21

234(23861)

1700

235

351.1(35.8)

YAH-15

HJ-21B1

SJ-21A1

CAH-24

234(23861)

1400

293

651.2(66.4)

YAH-15

HJ-21B1

SJ-21A1

CAH-32

240(24464)

1200

530

598.4(61)

YSH-21

-

-
