三爪高速中空液压卡盘(大孔径)TF-3CA/3XA

品牌: 台湾通福TONFOU

爪数: 三爪

动力类型: 液压

特殊用途类型: 中空

可替换商品
尺寸 规格 下载


产品尺寸

规格\型式TF3C-6A5TF3C-8A6TF3X-10A8TF3X-12A8TF3X-12A11
A175215254318318
B75108.5113137126
D2025303030
E3022.5183322
F82.563106.36139.719139.719196.8
C (H6)140170220300300
H104.78133.4171.45171.45235
J1616202020
K6xM106xM126xM166xM206xM20
L526678110110
M57566
N (Max)3246516868
N (Min)29.254246.66363
O (Max)2425.534.553.553.5
O (Min)7.510.5121919
P (Max)2531.526.53726
P (Min)12.514.57.5143
R1214162121
S1925252828
T3237425252
U (Max)M60x2.0M74xP2.0M87x2.0M115x2.0M115x2.0
V---6xM16-
W668296127127
X1616162020
Y3645606060
A16580102140140
M1M8M8M10M10M10
t55555
参考图Fig1Fig1Fig1Fig2Fig1


产品规格

规格\型式TF3C-6A5TF3C-8A6TF3X-10A8TF3X-12A8TF3X-12A11
通孔径 (mm)526675100100
柱塞行程 (mm)1217192323
爪行程 (直径)(mm)5.57.48.810.610.6
最大拉杆推力 (kgf)22003400430055005500
最大夹持力/油压压力 (kgf) / (kgf/cm²)5700 / 188700 / 1811000 / 27.514300 / 19.514300 / 19.5
最大速度 (r.p.m.)60004600420033003300
重量 (kg)14.224.537.46161
适合油压缸RCS-8RCS-10RCS-10XRC-15RC-15
适合生爪HC06HC08HC10HC12HC12
适合硬爪HJ06HJ08HJ10HJ12HJ12


Model 2D pdf 2D dwg 3D step
