品牌： 韩国瑞岩SEOAM
爪数： 四爪
动力类型： 液压
特殊用途类型： 中实
Item Model | A | B | C | F | G | H | J | K | L | M | N Max | N Min | O Max | |
CASLF-32 | 800 | 150 | 380 | 6 | - | 330.2 | - | 8-M24 | 31 | 76.2 | 101 | 85.7 | - | |
CASF-40HC | 1000 | 180 | 520 | 8 | - | 463.6 | - | 8-M24 | 32 | 76.2 | 207 | 154 | - | |
Item Model | O Min | P Max | P Min | Q | R | S | T | V | W | X | Y | Z | ||
CASLF-32 | - | 35 | -3 | 75 | 25.5 | 60 | 8 | M30X3.5 | - | 52 | 114 | 83 | 165 | |
CASF-40HC | - | 32 | -25 | 110 | 30 | 68 | 0 | M36X4.0 | - | 60 | - | 110 | 270 | |
Spec Model | Order NO. | Spindle nose NO. | Jaw stroke(Diameter) mm | Plunger stroke mm | Gripping Max | Gripping Min | Max. permissible input force KN(kgf) | |
CASLF-32 | 1ASLF32 | - | 30.6 | - | 38 | 800 | 211 | 120(11760) |
CASF-40HC | 1ASG40HC | - | 46 | 30 | 57 | 1000 | 187 | 180(18348) |
Spec Model | Max. static gripping force KN(kgf) | Max. Permissible speed r.p.m | weight(With standard soft jaws) | Gd moment of inertia | matching cylinder | Matching hard jaw | Matching soft jaw | |
CASLF-32 | 215(21070) | 650 | 341 | 23.8(2.43) | YAS,C,P,T-200 | HJ-32A1 | SJ-32A1 | |
CASF-40HC | 320(32653) | 500 | 710 | 91(9.28) | YAST-245, YAST-250S | HJ-40A2 | SJ-40A2 | |
| Model | 2D pdf | 2D dwg | 3D step |
|---|---|---|---|
| CASLF-32 |
|
|
|
